LNG Factory Direct Sale Stainless Steel Liquid Oxygen Cryogenic Tank

1 piece
MOQ
$19,200.00(>=1 pieces)
Price
LNG Factory Direct Sale Stainless Steel Liquid Oxygen Cryogenic Tank
Features Gallery Product Description Request A Quote
Features
Specifications
Condition: New
Video Outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: Hot Product 2022
Warranty Of Core Components: None
Core Components: Other
Dimension(L*W*H): 2200x2150x2914mm
Capacity: 5000L
Weight: 3700
Volume (m³): 10-50
Inner Material: SUS30408 GB/T24511
Outer Material: Q345R GB/T713
Design Pressure(MPa): 2.35Mpa
Max Working Pressure(MPa): 2.35Mpa
Design Standard: TSG21,GB/T150,GB/T18442-2019
Working Temperature(℃): -196 - 50 ℃
Warranty: 1 Year
Key Selling Points: Long Service Life
Applicable Industries: Manufacturing Plant, Energy & Mining, Other
Showroom Location: None
Diameter:: 2200x2150x2914mm
Application Medium:: Lng
Design:: Vertical
Maximum Filling Rate: 90%
Chassis Size(L*W):: 2000*2000mm
Supercharger:: 25Nm³/h
Vaporizer:: 100Nm³/h
Working Temperature(℃):: -196 / 50 ℃
Basic Infomation
Payment & Shipping Terms
Supply Ability: 100 Piece/Pieces per Month
Product Description
Main Features
(1)Our storage tank are both vertical and horizontal which contain LO2,LN2,LAr,LCO2,taking the type of vacuum powder isolation or high vacuum multi-layer interwining isolation. These tanks have the features of good adiabaticity, compact structure, convenient operation and maintenance, and apply widely to machinery, chemical, metallurgy, medical, food, mine, electronic, fuel gas, industry etc.

(2)The design and fabrication for all tanks equip high quality appendix and imported paint, through high vacuum mass spectrometer leak test, the index for vacuity, daily vaporization rate, leak rate higher than the requirement of national standards. So they should be an ideal choice of customer.

(3)Vacuum powder insulation cryogenic liquid storage tank is used for storage and supply of cryogenic liquid like liquid oxygen, liquid nitrogen, liquid argon and liquid carbon dioxide .It has advantages of area-saving, safe, reliable and convenient maintenance, etc, and has been widely used ingas,chemical,mechanical,metallurgy,electronics,medical,glass,mining,nuclear power and other industries. Insulation method: High vacuum multilayer insulation, vacuum powder insulation
Base form: Outrigger type
Filling medium: LO2, LN2, lar
Volume specification: 10M ³、 15m ³、 20m ³、 30m ³、 38m ³、 50m ³、 80m ³、 95m ³、 142.5m ³
Pressure rating: 0.8MPa, 1.2MPa, 1.6Mpa
Technical features:
1. The tank body adopts high-vacuum winding insulation design and auxiliary special high-vacuum maintenance technology, which
has good thermal insulation effect and low LNG evaporation.
2. The tank structure design is more reliable, and the product configuration is more reasonable.
3. Advanced shot blasting and rust removal technology, using high-reflective imported brand paint, long quality assurance
period.
4. You can choose to install flow meters and remote monitoring to realize digital and information management.
List of parameters of oxygen, nitrogen and argon (strain hardened) storage tanks
model
Effective volume
Geometric volume
Inner container
Dimensions (mm)（mm）
Empty weight
（Kg）
Full weight
（Kg）LNG/LO2/LN2/Lar
Evaporation rate
ZBDY10/0.8-W strain
10m³
10.53m³
0.84
0.8
S30408
Φ2100×7182
5500
LO2/LN2/LAr
16910/13580/19460
≤0.55（Liquid nitrogen）
ZBDY10/1.6-L strain
10m³
10.53m³
1.68
1.6
S30408
Φ2100×7070
5800
LO2/LN2/LAr
17210/13800/19760
≤0.55（Liquid nitrogen）
ZBDY10/1.6-W /strain
10m³
10.53m³
1.68
0.8
S30408
Φ2100×7182
7250
LO2/LN2/LAr
16910/13580/19460
≤0.53（Liquid nitrogen）
ZBDY10/3.5-L /strain
10m³
10.53m³
3.8
3.5
S30408
Φ2100×7070
7300
LO2/LN2/LAr
18710/15380/21260
≤0.55（Liquid nitrogen）
ZBDY15/0.8-L/strain
15m³
15.8m³
0.84
0.8
S30408
Φ2500×6935
6800
LO2/LN2/LAr
23915/18920/27740
≤0.53（Liquid nitrogen）
ZBDY15/0.8-W /strain
15m³
15.8m³
0.84
0.8
S30408
Φ2500×6651
7000
LO2/LN2/LAr
24115/19120/27940
≤0.53（Liquid nitrogen）
ZBDY15.8/1.6-L/strain
15m³
15.8m³
1.68
1.6
S30408
Φ2500×6935
7600
LO2/LN2/LAr
24715/19720/28540
≤0.53（Liquid nitrogen）
ZBDY21/0.8-L /strain
20m³
21m³
0.84
0.8
S30408
Φ2500×8610
9100
LO2/LN2/LAr
31940/25260/37020
≤0.49（Liquid nitrogen）
ZBDY21/1.6-L /strain
20m³
21m³
1.68
1.6
S30408
Φ2500×8610
10200
LO2/LN2/LAr
33040/26360/38120
≤0.49（Liquid nitrogen）
ZBDY31/0.8-L/strain
30m³
31.6m³
0.84
0.8
S30408
Φ2500×11960
11000
LO2/LN2/LAr
45236/35258/52890
≤0.43（Liquid nitrogen）
ZBDY33/1.2-L strain
30m³
1.32
1.2
S30408
Φ2500×12707
12200
乙烯C2H2:27800
≤0.2（乙烯）Ethylene
ZBDY31/1.6-L /strain
30m³
31.6m³
1.68
1.6
S30408
Φ2500×11960
12540
LO2/LN2/LAr
46776/36798/54429
≤0.43（Liquid nitrogen）
ZBDY40/0.86-L /strain
38m³
40m³
1.00
0.86
S30408
Φ3004×10191
16200
LO2/LN2/LAr
59558/46904/69248
≤0.37（Liquid nitrogen）
ZBDY52/0.8-L /strain
50m³
52.6m³
0.84
0.8
S30408
Φ3004×10900
21400
LO2/LN2/LAr
74750/58100/87500
≤0.35（Liquid nitrogen）
ZBDY52/1.6-L/strain
50m³
52.6m³
1.68
1.6
S30408
Φ3000×12750
21600
LO2/LN2/LAr
78450/61800/91200
≤0.34（Liquid nitrogen）
ZBDY80/0.8-L /strain
80m³
84.3m³
0.84
0.8
S30408
Φ3508×14505
27700
LO2/LN2/LAr
118980/92340/139380
≤0.28（Liquid nitrogen）
ZBDY100/0.8-L /strain
95m³
100m³
0.84
0.8
S30408
Φ3508×16727
31100
LO2/LN2/LAr
139495/107860/163720
≤0.25（Liquid nitrogen）
ZBDY100/1.6-L /strain
95m³
100m³
1.68
1.6
S30408
Φ3508×16727
35000
LO2/LN2/LAr
143395/111760/167620
≤0.25（Liquid nitrogen）
ZBDY150/0.8-L /strain
142.5m³
150m³
0.84
0.8
S30408
Φ3800×19600
57600
≤0.225（Liquid nitrogen）

model

Effective volume
Inner container
Dimensions（mm）
Empty weight
/Full weight
(%/d)/Evaporation rate
pressure（MPa）
temperature（℃）
design pressure
Work pressure
set tempreture
Operating temperature
Length×width×height
ZBDY5/2.2-L
5m³
2.32
2.2
-40/50
-35
Φ2000×4673
4700
9776
≤35 KPa/24h
ZBDY10/2.2-L
10m³
2.32
2.2
-40/50
-35
Φ2100×7022
7530
17680
≤35 KPa/24h
ZBDY15/2.2-L
15m³
2.32
2.2
-40/50
-35
Φ2400×7040
9600
29900
≤35 KPa/24h
ZBDY21/2.2-L
20m³
2.32
2.2
-40/50
-35
Φ2400×8712
11600
31900
≤35 KPa/24h
ZBDY31/2.2-L
30m³
2.32
2.2
-40/50
-35
Φ2400×12077
16530
46983
≤35 KPa/24h
Zhangjiagang Blue Sky Cryogenic Technology Co., Ltd. is located in Zhangjiagang City, Jiangsu Province, a civilized and sanitary city. It is committed to a complete set of solutions for cryogenic equipment and its technical application. We have a professional development team and installation service team. Staff composition. The key members concurrently serve as the National Gas Cylinder Standardization Committee, the Cryogenic Subcommittee of the Cylinder Standardization Committee, the China Road Transport Association and other industry experts, and participate in the drafting of national standards for related products.

The company is mainly engaged in LNG/IG cryogenic storage tanks, LNG/IG cryogenic gas cylinders, LNG vehicle cylinders and other products; LNG/IG vaporizers, LNG/IG pressure regulating metering skids, IG gas mixers and other complete sets of gas supply devices; LNG/ IG engineering complete set of supply, installation, after-sales maintenance and other services.

We uphold the values of "honesty-based, trust-based", deep cultivating technology in the low temperature field, focusing on gas equipment applications, diligent in learning, and continuous improvement; in order to provide customers with thoughtful one-stop service, at the same time, the company and the industry chain Relevant well-known key enterprises have established long-term and stable deep strategic partnerships, exchange what is needed, work together, and jointly contribute to our "blue sky and green land".
Q1: Are you a manufacturer or a trading company?
A1: We are a factory direct selling trading company, and have got the permit of export for years as well.

Q2: Can I print our own logo on package?
A2: Sure! Customized package and OEM printing are available.

Q3: What's the payment terms?
A3: Payment<=10,000USD, 100% in advance. Payment>10,000USD, 50% T/T in advance ,balance before delivery.

Q4: What's your delivery time?
A4: Usually 15-25 days, depending on the quantity you ordered.
