| Coating color | dark blue, dark green, white, and customized |
| A standard steel plate size | effective size 2400mm x 1200 m |
| Steel plates thickness | 3mm - 12mm, depends on the diameter & height |
| Coating thickness | 0.25mm - 0.4mm, two coatings internal and external |
| Acid and alkalinity proof | standard coating suits for PH3 - PH11, special coating suits for PH1 - PH14 |
| Adhesion | 3,450N/cm |
| Elastic | same as steel sheet, around 500KN/mm |
| Hardness | 6.0 Mohs |
| Service life | >30 years |
| Spark test | >1500 V |
| Permeability | gas and liquid impermeable |
| Easy yo clean | smooth, glossy, inert, anti-adhesion |
| Corrosion resistance | excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil, salt fox, organic and inorganic compounds |
Short construction period, cost-effective tank solution
Superior corrosion resistance, service life is more than 30 years
Easy to install, no need for big installation equipment and/or very skilled labors
Tank volume can be easily expanded
It can be dismantled, removed and relocated
Elegant appearance, tank color can be customized
Why Choose Center Enamel Glass-Fused-to-Steel Tanks
Cutting edge enameling technology to secure the product performance
The first and most experienced Glass-Fused-to-Steel tanks manufacturer in Asia
Innovative enameling protection on sheet' s four edges and bolt holes
Product meet or exceed AWWA D103-09, OSHA, ISO/EN 28765, NSF61, NFPA etc. international standards
Certified by ISo9001, NSF61, LFGB, BSCI etc. international qualification system
Mature exporting experience with projects reference in more than 60 countries in the world
Quick installation lowest maintenance cost
Quality Control
Raw material test: ingredient analysis, impurities test
Formula finalizing small sample test: enamel fluidity test, chromatic difference analysis, enamel burning experiment acid, and alkali resistance test, glossy, adhesion test etc.
Middle stage product test: magnify experiment simulated operation environment
Destructive testing: impact test, 1500V holiday test, sliced electric microscope analysis
